Pallet Truck

HL series Scale Hand Pallet Truck

HL
The HL scale pallet truck is a simple, economical and robust tool to be used for lifting and weighing of transported loads. Thanks to the 4 load cells it is able to be very precise and functional in all internal weighing operations; ideal for checking incoming goods, avoiding overloads and determining shipping weights.
Quantity:
Contact Now
add to cart
All Products

Name:HL series Scale Hand Pallet Truck

Features of HL series Scale Hand Pallet Truck

The HL scale pallet truck is a simple, economical and robust tool to be used for lifting and

weighing of transported loads. Thanks to the 4 load cells it is able to be very precise and functional in all internal weighing operations; ideal for checking incoming goods, avoiding overloads and determining shipping weights.

Model
Pallet Truck
HL20
Pallet TruckHL20PPallet TruckHL25Pallet TruckHL25PPallet TruckHL30
PumpAC castingAC castingAC castingAC castingAC
With/Without PrinterWithout PrinterWith PrinterWithout PrinterWith PrinterWithout Printer
Capacitykg20002000250025003000
Fork heightmm80-20580-20580-20580-20580-205
Steering wheelmmφ180x50φ180x50φ180x50φ180x50φ180x50
Single load rollermmφ74x93φ74x93φ74x93φ74x93φ74x93
Tandem load rollermmφ74x70φ74x70φ74x70φ74x70φ74x70
Size of forkmm160x60160x60160x60160x60160x60
Width over forksmm550/680550/680550/680550/680550/680
Fork lengthmm1150/12201150/12201150/12201150/12201150/1220
BatteryDC 6v/4.5ahDC 6v/4.5ahDC 6v/4.5ahDC 6v/4.5ahDC 6v/4.5ah
Charger100V-240V100V-240V100V-240V100V-240V100V-240V
Paper for printer (thermal paper )mm//57X50//57X50//
N.Wkg106/108110/112122/124126/130128/130
Packing2pcs/pallet2pcs/pallet2pcs/pallet2pcs/pallet2pcs/pallet
Packing sizemm2300X700X7602300X700X7602300X700X7602300X700X7602300X700X760
2300X800X7602300X800X7602300X800X7602300X800X7602300X800X760
