YL600 All Electric Drum Dump Truck

YL600
The all-electric drum dump truck makes the task of handling plastic, fiber and steel drums easy. This is the most ergonomic equipment available for transporting, maneuvering, weighing and dispensing drums in a model suitable for most applications.
Quantity
Contact Now
add to cart

The all-electric drum dump truck makes the task of handling plastic, fiber and steel drums easy. This is the most ergonomic equipment available for transporting, maneuvering, weighing and dispensing drums in a model suitable for most applications.

Drum Dump Truck is Capable of removing or placing drums from pallets, pallet racks, cabinets, overflow pallets and conveyors, as well as distributing by weight, without requiring several pieces of equipment in a crowded production area.

Includes safety-covered gear for your protection

- Drum Dump Truck Features durable stress relieved welded joints for years of use

- Drum Dump Truck Power-driven wheels plus full-featured hydraulic lifting and tipping mean that any operator can move the drums. Eliminates operator effort when shifting 600 kg/1,200 lbs. loads while reducing injuries from heavy lifting by more than 50%.

- Drum Dump Truck Motorized drum handlers offer significant cost savings by eliminating the need for forklifts and feature fully adjustable and programmable controls with speed control from 1-2.5 mph.

- Drum Dump Truck The exclusive automatic grip lock of will not allow the drum to fall off;

- Drum Dump Truck can easily handle inclines up to 5 degrees.

Model
Drum Dump Truck
YL600
Drive Type Full Electric
Operating Type Walkie
Rated Load Capacity  kg600
Drum Size 30 gallon (Ø450x700), 55 gallon (Ø572x900) steel, 210L plastic
Lifting Height        mm2400
Turning Radius            mm1500
Max. Grade ability (Fully-loaded/no-loaded)%3/5
Driving Wheel Size      mmØ250*80
Tire Polyurethane
Controlling Type Electromagnetic brake
Drive Motor Power          KW1.2
Lifting Motor Power          KW2.2
Noise Level                db(A)<70
BatteryV/Ah24/210
ChargerV/A24/30
Rotating Range (degree)°140°
Overall Size mm2270x1170x1860
Net Weightkg890
